Quantity | Unit price |
---|---|
1000 - 4999 | $0.2247 |
5000 - 9999 | $0.2022 |
10000 - 24999 | $0.1821 |
25000 + | $0.1638 |
File is successfully downloaded
Sorry, but the requested document is no longer available. please contact our customer support team for further assistance
File is successfully downloaded
Sorry, but the requested document is no longer available. please contact our customer support team for further assistance
Anchor Length | 13.6 mm |
---|---|
Anchor Length | 0.535 in |
Compatible Hole Diameter Range | 6.2 mm |
Compatible Hole Diameter Range | 0.243 in |
Compatible Hole Diameter | 6.2 mm |
Compatible Hole Diameter | 0.243 in |
Compatible Panel Thickness Range | 7.6 mm |
Compatible Panel Thickness Range | 0.300 in |
Head Diameter | 11.5 mm |
Head Diameter | 0.453 in |
Head Height | 1.7 mm |
Head Height | 0.065 in |
Operating Temperature Range | -40 - 85 °C |
Operating Temperature Range | -40 - 185 °F |
Colour | Natural |
Material | Nylon |
Full Material | Nylon 6/6 |
Rivet Head Shape | Pan |
Rivet Fitting Style | Push-In |
Material Flammability Standard | UL94 V-2 |
